FLYFUN 60A V5 ESC (3S-6S)
★★★★★
![]() |
|
| 60A V5 | |
| p/n | 30214101 |
| Cont./Peak Current | 60A/80A |
| Input | 3-6S LiPo |
| BEC | Switch Mode: 5.2V/6V/7.4V, 8A/20A |
| Input /output wire | 14AWG-150mm |
| Input connector | NO |
| Output connector |
4.0mm Gold Connectors (Female) |
| Size (mm) | 68.8x34.6x18 |
| weight (g) | 73.5 |
| Reverse Brake Mode | Supported |
- ESC programmable through Transmitter and LED program card (purchase separately)
-
DEO Technology / Active Freewheeling
The DEO technology (Driving Efficiency Optimization) implemented in the ESC has multiple advantages: - Rapider and smoother throttle response, better stability and flexibility during flight.
- Higher driving efficiency, longer flight time.
- Lower ESC temperature, more reliable operation.
- Soft Start-ups & Reverse Brake
- High-power BEC: High-power switch-mode BEC with continuous/peak current of 8A/20A and voltage adjustable among 5.2V, 6.0V & 7.4V allows users to have more electronic devices or devices with higher power like servo, flight controller, and on-board light on their aircraft.
- Multiple Protections: Multiple protection features include start-up, over-current, ESC thermal, capacitor thermal, overload, throttle signal loss (or Fail Safe), and abnormal input voltage effectively prolongs the service life of the ESC.
- PWM is 16KHz
- Comes with manufacturer limited warranty for normal use.
- learn more about HOBBYWING warranty program visit here.
Accessories available
- UBEC-10A (2-6S)(sold separately)
- UBEC 8A (2-3S)UBEC 8A (2-3S)(sold separately)
- UBEC 5A HV (3-10S)(sold separately)
- LED program Box(sold separately)
Download
Related Products
- UBEC-10A (2-6S)(sold separately)
- UBEC 8A (2-3S)UBEC 8A (2-3S)(sold separately)
- UBEC 5A HV (3-10S)(sold separately)
- LED program Box(sold separately)
